Sihui Fuji se yon manifakti elektwonik vize nivo bon jan kalite mond-klas.Nou ka bay yon solisyon konplè yon sèl-stop soti nan PCB konsepsyon ~ PCB ~ PCBA manifakti. Segondè fyab, kalite siperyè, ak tan livrezon kout se sa nou fè efò fè.
Layout Plant
Kapasite pwodiksyon SMT
|
Liy |
Ekipman |
Min pati |
SMT Kapasite /H |
Liy kapasite/M |
|
Liy 1 |
KE2060M |
0402 |
|
|
|
Liy 2 |
RX-8 |
0201 |
100,000 |
57,200,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
Liy 3 |
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
|
RS-1R |
0201 |
47,000 |
26,884,000 |
|
Liy 4 |
RX-8 |
0201 |
100,000 |
57,200,000 |
|
|
RS{{0}XL |
0201 |
47,000 |
26,884,000 |
|
|
RS{{0}XL |
0201 |
47,000 |
26,884,000 |
|
Kapasite total:300 milyon pwen / Mwa |
||||
|
Liy |
Pwosesis |
Mak |
Modèl |
Kapasite Jeni |
Min PCB (L * W) |
Max PCB (L * W) |
|
|
Liy 4 |
Lazè make |
Riis |
RTM-C450 |
mak lazè |
�% b10.02um |
50x50mm |
450x450mm |
|
|
Enpresyon |
gkg |
GKG |
enprime |
± 12um/±6σ |
50x50mm |
870x610mm |
|
|
SPI |
Sinik - Tek |
S8080L |
rezolisyon |
13 |
50x50mm |
630x5550mm |
|
|
SMT 3sets |
JIKI |
RX{{0}%/ RS{{1}RS /RS1-XL |
X/Y presizyon aks |
± 35um |
50x50mm |
950x370mm |
|
|
AOI anvan reflow |
Sinik - Tek |
S510D |
rezolisyon |
10um |
50x50mm |
550x450mm |
|
|
N2 raflanti |
Jingtuo |
JTR-1003N |
Zòn tanperati |
10 |
W: 50mm |
W: 450mm |
|
|
AOI apre reflow |
Sinik - Tek |
S510D |
rezolisyon |
10um |
50x50mm |
550x450mm |
DIP layout ak kapasite
1, Vag soude: 3 liy ak 4 zòn monte-desann prechofe ak aparèy N2, bon jan kalite a soude ak fyab se ekselan.
2, seleksyon soude: 1 liy ak gwo presizyon, segondè fyab ak ti pèt soude.
|
Liy |
Pwosesis |
Mak |
Modèl |
Prechofe |
Max PCB lajè |
Ba soude |
Kapasite (㎡) |
|
PLONJE #1 |
vag |
Ridong |
PEAK-450 |
4 zòn 2 bò |
450mm |
SAC305 |
10,000 |
|
PLONJE #2 |
vag |
jansenk |
ENTELIJ-450-H |
4 zòn 2 bò |
450mm |
SAC305 |
10,000 |
|
PLONJE #3 |
vag |
jansenk |
ENTELIJ-350-H |
4 zòn 2 bò |
350mm |
SAC305 |
8,000 |
|
PLONJE #4 |
vag |
jansenk |
ENTELIJ-610-H |
4 zòn 2 bò |
540mm |
SAC305 |
15,000 |
|
PLONJE #5 |
seleksyon |
Xinrui |
SW{{0}s |
Min gwosè 50x50mm |
Gwosè maksimòm 300x250 |
SAC305 |
1,000 |
